Datamax I Class heat shrink tubing setup pictures

This page contains pictures to illustrate the correct setup for printing on heat shrink tubing on a Datamax I-4308, I-4208. A similar setup can be used on the Mark III-4310 and Mark III-4212 newer models.

1
2
3
4
Proper Ribbon setup for CSI ribbon Ribbon feed location Ribbon rewind Ribbon rewind picture #2

Tubing feed Tubing feed with media sensor (white chalk line should in center of tubing Exit Side view of ribbon and tubing loaded in Printer
5
6
7
8
